Introducing the CHD 7A, a versatile mobile POS system designed to meet all your needs with its compact and modern design. Slightly larger than the size of your palm, this all-in-one device features a 7" LCD display, an easy-to-load printer with a 50 mm paper roll capacity, a built-in battery, and NFC capabilities. Enhance its functionality with the optional miniPOS cloud sales app, transforming the CHD 7A into a standalone, jet cloud-based sales system reachable from anywhere and anytime.
| Sisteminiai | |
|---|---|
| Processor | Quad-core ARM Cortex-A55: RK3566 |
| GPU | Mali-G52 GPU |
| Main frequency | up to 2.0 GHz |
| OS | Android 11 Red Velvet Cake |
| RAM | 2 GB |
| Memory | eMMC 16GB |
| SIM | yes |
| Garsas | Beeper |
| Wi Fi | Wi-Fi 802.11b/g/n/ac (2.4GHz+5GHz) |
| Bluetooth | 5.0 |
| SD slot | up to 128 GB |
| NFC | yes |
| Išoriniai I / O portai | |
|---|---|
| USB ports | USB-A: 2 x USB HOST; USB type-C: 1 charging, USB UFP (client) |
| Stalčiaus jungtis | 1 x RJ11, 9V |
| Maitinimas | |
|---|---|
| Input voltage | Integrated battery: 2600mAh |
| Maitinimo blokas | Charger: DC 5V 2A USB type-C |
| Parametrai | |
|---|---|
| Kliento displėjus | 1.47" LCD |
| Darbinė temperatūra | 0°C to 45°C |
| Saugojimo temperatūra | -20°C to 70°C |
| Svoris | 850g inclusive paper roll and acessories |
| Išmatavimai | 115 x 68 x 283 mm |
| Ekranas | |
|---|---|
| Išmatavimai | 7" LCD |
| Tipas | Capacitive multi-touch screen |
| Rezoliucija | 1024 x 600 |
| Spausdintuvas | |
|---|---|
| Roll diameter | Max 50 mm |
| Popieriaus plotis | 58 mm |
| Atsparumas trinčiai | 50 km or more |
| Nukirpimas | manual cutter |
| Programinė įranga | |
|---|---|
| Programa | miniPOS (Optional) |
| Cloud solution | optional |
